The Babcock-Davis Personnel Roof Hatch is improved to offer superior weather resistance in an easy to order stock roof hatch. The industry’s leading roof hatch is customizable, sized for OSHA compliant safety railings and available in a variety of materials and finishes.
Features
Miami-Dade & Florida Approved up to 20ft2
Safety Railing Ready
Superior Powder-Coat Finish
Easy Gas Spring Operation
Modular Bridge 575-25 for use with Staht t25 or t60 Digital Pull Testers**.
Max Load 25kN; 575mm Span
Adjustable leg height, maximum clearance 544mm
Kit bag with shoulder straps and internal roll bag included.
**t25 & t60 Digital Pull Testers are not included.
For testing safety eye bolts, lifting eyes and load bearing connections.
Connects to the Drop Rod for t60 and t25 (Part Nos 600-008, 600-045).
A captive pin prevents inadvertent loss and enables faster engagement with the eyebolt.
Reduce the risk and liability associated with unauthorized ladder use with the lightest, longest-lasting, easiest-installing ladder guard on the market. Made in the USA of 5052 aluminum, the EZ Ladder Guard is designed to eliminate pinch points associated with hinged, enclosure-style ladder guards. EZ Ladder Guard is durable, weatherproof and compatible for use with all ladder lifeline systems.
Simply hook over a rung and securely lock in place for restricted access.
The EZ Ladder Guard is available in two widths. The standard 15" width is compatible with most commercially available permanent ladders. The 18" width is designed to be used especially with the Diversified EZ Ladder.
FL-LGEXIST-02Material: 5052 AluminumDimensions: 78”height x 15” wide x .125” thickWeight: 16 lbs
FL-LGDFP-02 (designed for use with the DFP EZ Ladder)Material: 5052 AluminumDimensions: 78”height x 18” wide x .125” thickWeight: 18 lbs
In some instances, the truss system found in your building may be strong enough to support a fall protection system. By permanently attaching a D-Ring anchor to the bottom chords of an overhead truss system, we can create an OSHA-compliant anchor point that serves as part of a fall arrest system. Unlike our Connect Safe Portable Truss Anchors, the Fixed Truss Single Point Anchor is mechanically attached with steel plates and a threaded bolt and nut combination.
Installation Notes:Truss anchorage locations must be approved by a safety engineer or a qualified person and must meet all of the requirements noted in the Connect Safe Fixed Truss Anchor Instruction Manual.
Bracing shall be straight, undamaged, and meet the original design intent
The span and loading of the truss affects the allowable concentrated load that may be applied to the truss. It must be capable of withstanding a concentrated load of 900 pounds with a safety factor of two
No more than one user is permitted at a time per truss
Do not attach to a truss that is smaller than 18 inches in height
The truss must be inspected by an engineer or qualified person for structural integrity which includes but is not limited to corrosion, end connections, size, load capacity, welds, existing loading, bracing, span, or any other unsafe conditions
